Day 1
Lesson 1: Solid Edge – Getting Started
Lesson 2: Ordered - Reference Planes
Lesson 3: Ordered - Sketching Basics
Lesson 4: Sketching Constraints
Day 2
Lesson 5: Sketching Editing and Helpful Tools
Lesson 6: Ordered - Base Features
Lesson 7: Ordered-Profile Based Features
Lesson 8: Ordered – Treatment Features
Lesson 9: Ordered – Patterning & Feature Reuse
Day 3
Lesson 10: Building assemblies
Lesson 11: Manipulation of Assemblies
Lesson 12: Creating drawings of 3D models
Day 4:
Lesson 13: Dimensions and annotations
Lesson 14: Modifying draft documents and Design Manager
Lesson 15: Sheet Metal Design Introduction
Day 5:
Lesson 16: Sheet Metal Design Additional features
Lesson 17: Sheet Metal Features
Lesson 18: Deformation Features and Flat Patterns
Note (only applicable to Solid Edge courses): This course is intended for SE2020, if you choose to use SE 2019, contact us for appropriate part files.
